DIRECTIONAL ACOUSTIC DETERRENT DEVICE
EV-60HD
plus
plus
plus
plus
产品图片 1

Installation and Function

It can be fixedly installed at airport runways for long-range broadcasting, hailing, and acoustic- optical deterrence to achieve bird repelling and ensure airport operational safety. This device plays an important role in bird control and environmental management at airport runways.

Special Scenario Applications

The device can also be used for perimeter protection in special scenarios, such as key infrastructure and secure areas, achieving "detection and deterrence integration" for all-weather monitoring, warning, and rapid response.

Device Characteristics

The device is made of high-quality materials, featuring resistance to acid, alkali, and salt spray corrosion, and can withstand high-intensity impacts and vibrations. The sound beam transmission is highly directional, creating an effective dispersion range along its axis that causes discomfort to birds, achieving the repelling effect.

ACOUSTIC

DETERRENT

DEVICE

MODEL

EV-D

Rated Power

≤ 600W

Audio Frequency Response

400Hz-6000Hz

Peak Sound Pressure Level

(@1m)158dB±2dB

Directivity

8° @ -3dB

Effective Deterrent Distance (In Open Space)

1000m

Horizontal Motion Range

360° Omnidirectional Continuous Rotation

Horizontal Rotation Speed

One Circle in 24 Seconds

Vertical Motion Range

45°~ 180°

Pitch Rotation Speed

29s±1s

Raising Speed

29s±1s

Fold Down Dimensions(L×W×H)

945×682×670mm

Erect Dimensions(L×W×H)

945×550×913mm

Weight

132kg

Ingress Protection Grade

IP56



CONTROL HOST

Total Power Consumption

≤ 1000W

Power supply

AC220V/DC12V/DC24V

Dimensions(W×L×H)

440×370×143mm

Weight

9.5kg
